Product Description
Material: A2 stainless steelType: AB Hexagon self tapping screw DIN7976
| A | B | C | D | E | F | G | H |
| No.12 | 5.5mm | 1 1/2" | 38mm | 5/16" | 8mm | 5/32" | 4.15mm |
| No.12 | 5.5mm | 1 1/4" | 32mm | 5/16" | 8mm | 5/32" | 4.15mm |
| No.12 | 5.5mm | 1" | 25mm | 5/16" | 8mm | 5/32" | 4.15mm |
| No.12 | 5.5mm | 1/2" | 13mm | 5/16" | 8mm | 5/32" | 4.15mm |
| No.12 | 5.5mm | 2 3/4" | 70mm | 5/16" | 8mm | 5/32" | 4.15mm |
| No.12 | 5.5mm | 2" | 50mm | 5/16" | 8mm | 5/32" | 4.15mm |
| No.12 | 5.5mm | 3/4" | 19mm | 5/16" | 8mm | 5/32" | 4.15mm |
| No.12 | 5.5mm | 5/8" | 16mm | 5/16" | 8mm | 5/32" | 4.15mm |
Please Note: Specifications given are intended as a guide only. If critical to your project please check with us first.
